Okuma LH-35N CNC Lathes
Specifications
| Brand | OKUMA |
| Model | LH-35N |
| Type | CNC Lathes |
| Control | CNC (OSP 5000L) |
| ChuckSize | 18 inch |
| BarCapacity | 4.5 inch |
| Axis | 2 |
| Power | 30 hp |
| MaxRPM | 4000 rpm |
| TurningDia | 24 inch |
| Swing | 26 inch |
| MachiningLength | 60 inch |
| images | none |
| Length | 18’ |
| Width | 7’ |
| Height | 5.5' |
| Weight | 17,000 lbs |
| catalogid | 2539 |
| mfg | OKUMA |
| mpn | LH-35N |
| title | Okuma LH-35N CNC Lathes |
| joinSig |
Zero? Available Machines
Available Machine # Ez78685 | |
|
|
 | |
Available Machine # Ez18979 | |
| Specifications: Model LH 35N CNC control OSP 7000L 1996 (1997 software) Swing over bed 25.4 Swing over cross slide 14.4” Distance between centers. 72” Spindle speed range 20-2200 rpm Spindle bore 3.54 Bar capacity 3.15 Rapid traverse x & z 196 IPM & 392 IPM Main motor 30 hp. Front tool post box type 4 way auto Rear turret hex type 6 way auto Approximate weight 17,000lbs Dimensions 18’ x 7’ W x 5.5 H Voltage Currently 480/3/60 Equipped with: 18” Kitagawa 3-jaw hydraulic jaw Tailstock with hydraulic quill Steady rest Coolant Chip conveyor
|
   | |
