Okuma & Howa Millac 65V Vertical Machining Centers
Specifications
| Brand | OKUMA & HOWA |
| Model | MILLAC 65V |
| Type | Vertical Machining Centers |
| Control | CNC (Fanuc 15M) |
| Lower | 12 |
| X | 51.18 inch |
| Y | 25.51 inch |
| Z | 22.83 inch |
| Power | 30 hp |
| RPM | 3600 rpm |
| ATC | 30 |
| Upper | 32 |
| TableW | 179 inch |
| TableL | 138 inch |
| Axis | 3 |
| Dimensions | Floor space Wx Lx H 179inchx 138inch x 115inch |
| catalogid | 3719 |
| mfg | OKUMA & HOWA |
| mpn | MILLAC 65V |
| title | Okuma & Howa Millac 65V Vertical Machining Centers |
| joinSig |
Zero? Available Machines
Available Machine # Ez135832 | |
|
|
  | |
Available Machine # Ez54540 | |
| OKUMA & HOWA MILLAC 65V VERTICAL MACHINING CENTER Fanuc 15M 78” x 25” x 22” Specifications: Model Millac 65V CNC control Fanuc 15M Serial number 66742 Table dimensions 94” x 29” Max. table load 4,400 lbs. Travels, X x Y x Z 78” x 25” x 22” Cutting feed rate 0.039—196.86 ipm Spindle taper CAT 50 Tool stations 30 stations Tool change time 5 seconds Chip to chip -10 seconds Spindle speeds 20-3,600 rpm (2 steps) Spindle motor 15-18.5Kw Coolant tank 220 gallons Hydraulic tank 200 gallons Max. electrical draw 36 Kva Dimensions 9’ 6” H x 110” W x 126” L (front to back) Weight 26,400 lbs. The machine has been completely stripped, cleaned, repaired as required and painted. One very heavy duty, well-built machine. |
        | |
