Toyoda Fv1480 Vertical Machining Center

Specifications

ModelFV1480
BrandTOYODA
TypeVertical Machining Centers
ControlCNC (FANUC 18i-MB)
X55.1 inch
Y31.5 inch
Z27.6 inch
Power35 HP
RPM6,000 RPM
ATC30
TableW31.5 inch
TableL61 inch
TaperCAT-50
Axis3
Dimensions201.3inch x 172.2inch x 131.6inchH
Weight26,500 lbs
Length201.3 inch
Width172.2 inch
Height131.6 inch
catalogid604
mfgTOYODA
mpnFV1480
titleToyoda Fv1480 Vertical Machining Center

Zero? Available Machines

Available Machine # Ez12338

  • Stock#:Ez12338
  • Price:Call
  • Year:2009
  • Region:South
  • Condition:Used
SPECIFICATIONS: TABLE SIZE......................61" X 31.5" X-AXIS TRAVEL...................55.1" Y-AXIS TRAVEL...................31.5" Z-AXIS TRAVEL ..................27.6" MAXIMUM TABLE LOAD..............3,960 LB DISTANCE FROM TABLE TOP TO......7.9" TO 35.4" SPINDLE FACE SPINDLE DRIVE MOTOR ............35 HP SPINDLE OUTPUT TORQUE...........485 FT-LB SPINDLE TAPER...............CAT 50 SPINDLE SPEED ..................6,000 RPM SPINDLE TYPE....................GEARED HEAD RAPID FEEDRATE (X AND Y AXES)...945 IPM (24 M/MIN) RAPID FEEDRATE (Z AXIS).........708 IPM (18 M/MIN) MAXIMUM CUTTING FEEDRATE........708 IPM (18 M/MIN) TOOL STORAGE CAPACITY...........40 STANDARD FLOOR SPACE............201" X 174" X 132" EQUIPPED WITH: FANUC 18I-MB CNC CONTROL COOLANT THROUGH SPINDLE 12" CHUCK 4TH AXIS ALL AVAILABLE MANUALS


Available Machine # Ez8180

  • Stock#:Ez8180
  • Price:Call
  • Year:2009
  • Region:West
  • Condition:Used
TOYODA FV1480, Fanuc 18iMB, 55"x31"x27", 6K RPM, 60 ATC, CTS, 2009


Available Machine # Ez978

  • Stock#:Ez978
  • Price:Call
  • Year:2011
  • Region:Midwest
  • Condition:Used
Specifications: TABLE SIZE 61" x 31.6" X-AXIS TRAVELS 55.1" Y-AXIS TRAVELS 31.5" Z-AXIS TRAVELS 27.6" MAX TABLE LOAD 3,960 LBS. SPINDLE SPEED 6,000 RPM SPINDLE MOTOR 35 HP SPINDLE TAPER CAT-50 TOOL CHANGER 40 ATC DIMENSIONS 201" x 174" x 132" MACHINE WEIGHT 30,000 LBS. Equipped With FANUC 18i-MB CNC CONTROL COOLANT THROUGH SPINDLE 12" CHUCK 4TH AXIS ALL AVAILABLE MANUALS


Available Machine # Ez11206

  • Stock#:Ez11206
  • Price:Call
  • Year:2011
  • Region:Midwest
  • Condition:Used
X-TRAVEL: 55" Y-TRAVEL: 31.5" Z-TRAVEL: 27.6" SPINDLE SPEED: 6,000 PALLET SIZE: 61" x 31.5"
