Okuma MA-50HB Horizontal Machining Centers

Specifications

ModelMA-50HB
BrandOKUMA
TypeHorizontal Machining Centers
ControlCNC (OSP U100M)
X27.5 inch
Y31.5 inch
Z27.5 inch
Power27.5 HP
RPM10,000 RPM
ATC60
PalletW19.6 inch
PalletL19.6 inch
imagesnone
Weight40,000 Lbs.
Length195 inch
Width137 inch
Height128 inch
Taper50
catalogid944
mfgOKUMA
mpnMA-50HB
titleOkuma MA-50HB Horizontal Machining Centers

Zero? Available Machines

Available Machine # Ez4797

  • Stock#:Ez4797
  • Price:$65,000
  • Year:2001
  • Region:Midwest
  • Condition:Used
Specifications: Control OSP U100M Pallet Size 500mm (20") Number of Pallets 2 Max Pallet Load 1764 Lbs Pallet Index Time 2.0 Sec X-Axis Travel 27.55" Y-Axis Travel 31.5" Z-Axis Travel 27.55" Indexing 1° Spindle Motor 40/30 HP Spindle Speed 6,000 RPM Spindle Torque 210 ft lbs Spindle Taper CT 50 Rapids 1574 IPM Tool Changer 60 Position ATC Machine Weight 40,000 lbs Rough Floor Space 195"x137" Equipped With: Okuma OSP U100M Control High Pressure Coolant Chip Conveyor Oil Cooler 60 Station ATC


Available Machine # Ez14020

  • Stock#:Ez14020
  • Price:Call
  • Year:2003
  • Region:Midwest
  • Condition:Used
GENERAL SPECIFICATIONS: Longitudinal Table Travel (X-Axis) 27.55" Vertical Travel (Y-Axis) 31.5" Head Cross Travel (Z-Axis) 27.55" Pallet Dimensions 19.69"x19.69" Max. Pallet Load 1,764 Lbs Number of Pallets 2 (19.7"x19.7") Number of Index Positions 360,000 Spindle Taper No. 50 Number of Tool Positions 60 Machine dimensions 195"x137"x128"H Machine weight (approx.) 40,000 Lbs. EQUIPPED WITH: Okuma OSP-E100M CNC Controls Color display, Graphics, Animation, Machine Management Tool Breakage Detection & Comp., 320 Meters Program storage, Helical Cut, Skip Function, One Direction Position Change Work Coordinates, Exact Stop, Point Calc., Additional Pattern Cycle, 3D Simulation, Synchronized Tapping In/Out Variables, Area Machining, Playback (IMAP), Hig-G Hi Cut, I/M Switch, System Variables, Add Math Function, Sub Programs Cycle Time Reduction, Tool Data 200, Rotary Axis Inductosyn Scales Door Interlocks, Coolant Shower Wash, Air Nozzle, Air Through Spindle High Pressure Coolant Through Spindle, Oil hole, 60 Position Tool Changer Full 4th Axis 360,000 Position NC Table
