Okuma ES-L8 CNC Lathe

Specifications

ModelES-L8
BrandOKUMA
TypeCNC Lathes
ControlCNC (OSP U10)
BarCapacity2.44 inch
Axis2
Power15 HP
MaxRPM4200 RPM
TurningDia10.8 inch
Swing21.65 inch
MachiningLength19.68 inch
TailstockYes
LiveToolingNo
SubSpindleNo
Weight8,200 lbs
Length84 inch
Width68 inch
Height70 inch
ChuckSize8 inch
catalogid1636
mfgOKUMA
mpnES-L8
titleOkuma ES-L8 CNC Lathe

Zero? Available Machines

Available Machine # Ez15776

  • Stock#:Ez15776
  • Price:$16,500
  • Year:2001
  • Region:Midwest
  • Condition:Used
Specifications: Control OSP-U10L Max. Swing Over Saddle.... 17.7" Max. Turn Dia.......... 10.6" Max. Turn Length...... 19.68" Chuck Size.................... 8" Spindle Nose.. A2-6 Spindle Bore....... 2.44" Spindle Motor. 10 HP Spindle Speed..... 4,200 RPM X-Axis Travel....... 6.10" Z-Axis Travel..... 20.47" Rapid Traverse (X/Z)...... 591 IPM/ 787 IPM Turret Positions..... 8 Approx. Machine Dimensions.......... 83.1" x 60.2" x 65.8" Weight (Approx)......... 8,150 Lbs. Equipped With: OSP U-10L CNC Control 8" 3-Jaw Chuck Tailstock Misc. Tool Holders


Available Machine # Ez13936

  • Stock#:Ez13936
  • Price:$21,500
  • Year:2002
  • Region:West
  • Condition:Used
Specifications: Chuck Size 8" Max Swing 17.72" Max Turning Diameter 10.60" Max Turning Length 19.68" Spindle Bore 2.44" Spindle Nose A2-6 X/Z Travels 6.10" / 20.47" Rapid Traverse 787 ipm Turret Positions 8 Spindle Motor 10HP Bar Capacity 2" Spindle Speeds 0-4500 rpm Tailstock Spindle Diameter 3.54" Tailstock Spindle Taper MT5 Tailstock Spindle Travel 3.94" Machine Dimensions 84" x 68" x 70"H Machine weight 8,200 lbs Equipped With: Okuma OSP-U10L Control Kitagawa B-208 3-Jaw Hydraulic Chuck Tailstock Coolant System ID Toolholders OD Tool Wedges Tailstock & Chuck Foot Pedals Central Lube System RS232 Port Floppy Port
