Haas SL-20TB CNC Lathe

Specifications

ModelSL-20TB
BrandHAAS
TypeCNC Lathes
ControlCNC
ChuckSize10 inch
BarCapacity2.5 inch
Axis3
Power30 HP
MaxRPM3,400 RPM
TurningDia10.3 inch
Swing23 inch
MachiningLength24 inch
TailstockYes
Weight11,000 LBS
Length127 inch
Width74 inch
Height70 inch
catalogid1263
mfgHAAS
mpnSL-20TB
titleHaas SL-20TB CNC Lathe

Zero? Available Machines

Available Machine # Ez14927

  • Stock#:Ez14927
  • Price:Call
  • Year:2008
  • Region:West
  • Condition:Used
Specifications: Max Turning Diameter: 10.3" Max Turning Length: 20.0" Max Bar Capacity: 2.50" Swing Over Bed: 23" Distance Between Centers: 24" X Axis Travel: 8.45" Z Axis Travel: 20.0" Rapid Traverse X Axis: 710 IPM Rapid Traverse Z Axis: 710 IPM Spindle Nose: A2-6 Spindle Bore: 3.0" Spindle Speed: 3400 RPM Spindle Motor: 30HP Turret Capacity: 10 Stations Turret Index Time: 1 Second Tailstock Travel: 20.0" Tailstock Quill Dia.: 3.0" Tailstock Quill Stroke: 5.1" Tailstock Taper: MT-4 General: Power Source: AC 220 V, Three Phase, 60 Hz Overall Dimensions: 135" x 70" x 80" High Weight : 9,000 lbs Approx. HAAS SL-20TB Equipped With: Haas CNC Control with USB Port 15" Color Display 10" 3-Jaw Kitagawa Hydraulic Chuck 10-Station Turret Tool Presetter Programmable Hydraulic Tailstock Intuitive Programming System (IPS) Parts Catcher Rigid Tapping Coolant System with Tank Automatic Lubrication system Foot Operated Control for Chuck Chip Conveyor High Intense Lights Comes with Chip Conveyor, Levelling Pads, Manuals.
