Feeler HT-30SY CNC Lathe

Specifications

BrandFEELER
ModelHT-30SY
TypeCNC Lathes
ControlCNC (FANUC 18ITB)
BarCapacity3 inch
Axis4
Power30 HP
MaxRPM3500 RPM
TurningDia14.02 inch
Swing36.4 inch
MachiningLength27.8 inch
TailstockNo
LiveToolingYes
SubSpindleYes
Dimensions176inch X 76.8inch X 86.2inch
Weight14,330 Lbs
Length176 inch
Width76.8 inch
Height86.2 inch
catalogid2647
mfgFEELER
mpnHT-30SY
titleFeeler HT-30SY CNC Lathe

Zero? Available Machines

Available Machine # Ez5531

  • Stock#:Ez5531
  • Price:$99,900
  • Year:2011
  • Region:Midwest
  • Condition:Used
2011 Feeler HT-30SY CNC Turning Center with Sub-Spindle and "Y" Axis Specifications Control Fanuc 18iTB Swing Over Bed 36.4" Spindle Bore (Main) 3.6" Spindle Bore (Sub) 2.2" Max Bar Capacity (Main) 3" Max Bar Capacity (Sub) 1.7" Max Cutting Diameter 14" Max Cutting Length 27.8" Spindle Speed (Main) 3,500 RPM Spindle Speed (Sub) 6,000 RPM Spindle Motor(Main/Sub) 30/15 HP X-Axis Travel 7" + 3.2" Y-Axis Travel 3.9 ± 2" Z-Axis Travel 31.3" Rapid Traverse Rates (X/Z) 1,181 IPM Turret Positions 12 POS (BMT 60) Live Tool Motor 9 HP Machine Dims 176" x 76.8 x 86.2 Machine Weight 14,330 Lbs Equipped With: Simultaneously Control 4 Axis 3" Bar Machine Automatic Tool Presetter High Pressure Coolant Pump Box Way Construction LNS Quick Load Servo 80 S2 Barfeeder Chip Conveyor Pneumatic Parts Catcher Live Tooling (2 Z Axis and 2 X axis) Y Axis/Sub Spindle Set of 3 Jaw and 3J collet Chucks for Main and Sub
